Pioneer DJ DJM S11 Battle Mixer

Customizable touch screen

A 4.3-inch customizable touch screen gives all the information you need. Browse tracks, check waveforms, and dynamically change the texture of the music with TOUCH FX. With Touch MIDI you can directly control functions in your DJ software without touching your laptop.

Discover more

Customizable touch screen

Waveform screen

Spend more time focusing on your mix thanks to the high-frame-rate color touch screen, which shows everything from waveforms to BPM so you can stay in the zone. You can even customize it with your preferred style of layout.

Browse screen

Rapidly select tracks by checking the information on the screen – there’s no need to look at your laptop – and instantly see their playback status.

DECK 3/4 Control screen

Want to pack more sounds into your sets? Play up to 4 tracks or samples simultaneously with Deck 3/4 Control, an innovative feature that adds two extra decks – accessible via the touch screen. These additional decks let you control EQs, Hot Cues, pitch bend, and more.

Deck Move

Access two extra Deck 3/4 features with Serato DJ Pro. With Deck Move, you can seamlessly move tracks from deck 1 to 4 and deck 2 to 3. Use it to free up your main decks when mixing and scratching. Use Dual Deck control to adjust volume and effects for two decks at once.

Touch FX screen

Express yourself in new ways. Switch to the Touch FX screen and you can control 2 effects at the same time by tracing a finger across the surface while the other hand is scratching with the crossfader or finger drumming on the Performance Pads.

FX Setting screen

In the FX Setting screen, you can save 4 banks of effect types and parameters, then instantly call them up in different scenarios, e.g. when you’re battling, mashing up tracks, or playing a club set.

Touch MIDI screen

Touch MIDI offers four pages of presets that enable you to control functions in your DJ software without touching your laptop. The controls can also be custom MIDI mapped, enabling you to set things up to suit your style.

Expanded effects section

Spice up your sets with 22 Beat FX, including the new Fader Pitch and Helix. Smooth Echo is a new effect that you can automatically engage when you move the faders or hit the pads you’ve assigned as triggers.

Discover more

Expanded effects section

Smooth Echo

Assign the Smooth Echo effect to your choice from a selection of controls, e.g. a fader or pad. Turn on Smooth Echo with its dedicated button, and the echo will be triggered as soon as you move the relevant control. Its changeable parameters let you create new sounds.

22 Beat FX

Spice up your sets with all 15 Beat FX from the DJM-S9, plus 7 new ones including Fader Pitch and Helix. Trigger up to 6 more effects from your DJ software to create sounds your crowd has never heard before.

Improved Performance Pads

The 8 Performance Pads are bigger, making them easier to hit in energetic battles. In Serato DJ Pro, use Combo Pad mode to combine up to 4 different pad modes at once, and use Scratch Bank to call up assigned scratch samples by just tapping a pad.

Discover more

Improved Performance Pads

Combo Pad mode

Activate Combo Pad mode in Serato DJ Pro to use up to 4 different pad modes simultaneously (2 modes per channel, 4 pads per mode) and combine even more features.

Scratch Bank

With the new pad mode Scratch Bank, you can instantly call up scratch samples that you’ve assigned in Serato DJ Pro by simply tapping a pad. There’s no need to browse via the touch screen or your laptop.

Enhanced MAGVEL FADER PRO

We’ve enhanced the feeling of the MAGVEL FADER PRO and boosted its vertical rigidity by 30 percent. This means you can scratch with more confidence, while the tougher coating around the crossfader area reduces wear and tear.

Crystal-clear sound quality

The DJM-S11 inherits the raw and high-density sound from the DJM-900NXS2 thanks to studio-quality 64-bit mixing and dithering processing inside the DSP, and a low-jitter clock circuit and 32bit high-quality D/A converter in the master output section.

USB hub

Plug your DJ controllers and other devices – including selected units from other brands – into the dual USB-A ports to play with them.

MIDI controller

This device is fully MIDI assignable via USB. Send control information to external devices and use the mixer as a MIDI controller.

Serato DJ Pro

Connect your PC/Mac to use Serato DJ Pro. Use dedicated buttons for FX and advanced Serato features like Beat Jump, Slip mode, and Quantize.

Serato DVS

Use Serato DVS to control and scratch with CDJs or turntables.

Pitch ‘n Time DJ

Serato Pitch ‘n Time DJ Expansion Pack is included. Use Pitch Play, Flip, Key Shift and more features. The mixer is fully MIDI mappable too.

rekordbox

Connect your PC/Mac to unlock rekordbox Performance mode for free and use DVS mode with the dedicated control vinyl (available separately).

Two-channel scratch-style mixer – perfect for professionals

The DJM S11 is designed from the ground up for professional DJs. Moving on from the DJM-S9, the DJM S11 is jam-packed with features to deliver a unique and seamless mixing experience. From creating live mashups to full-blown scratch sets, the DJM S11 is the perfect companion for any DJ.

The beating heart of the S11 is the intuitive 4.3-inch touchscreen display, providing new and interesting ways to interact with sounds, songs, effects and more. Boasting an ultra-high frame rate, the touchscreen is smooth and easy-to-use. It acts as the main hub of the mixer, providing track info, waveforms, BPM info and much more. You can also customise the layout and look of the touchscreen to suit your needs so you’re always ready for the next battle.

Looking for a new way to add some flare to your sets? The Touch FX screen allows you to control up to two effects simultaneously using just your finger. You can even save and recall effects types and parameters so you can prepare your sets in meticulous detail.

Touch MIDI allows you to integrate and control functions within your chosen DJ software, directly from the mixer. You can customise the MIDI mapping for the mixer to cater to your needs.

Play up to four songs at the same time using only two decks

A world first. Ever wanted to get complex with your scratch sets but don’t have enough decks? Introducing Deck 3/4 control, providing two extra DJ decks via the touchscreen. Not only can you play songs through the virtual decks, but you can also control the EQ, Hot Cues, Pitch Bend and more. This means you can do a four-deck set with just two turntables/controllers.

Improved Magvel fader, larger pads and low-latency performance

Building on the design of its sibling (the DJM S9), the S11 delivers an experience like no other. The new and improved design boasts a strengthened Magvel Fader Pro for improved stability – perfect for even the most demanding scratch performances. The built-in performance pads have also been made larger, allowing you to trigger samples, finger-drum, incorporate sound FX and much more.

The audio fidelity has also been improved to deliver the best possible sound. The high-resolution audio is thanks to the 64-bit processing within the DSP, as well as a low-jitter clock circuit and a 32-bit premium-grade D/A converter for the master output section. The result is breath-taking sound quality, inheriting its raw sound from the industry-standard DJM-9000NXS2

Smooth Echo effect and Scratch Bank pad mode

As well as the improved design, the S11 introduces the new ‘Scratch Bank’ pad mode. This unique mode allows you to load scratch samples instantaneously from up to four banks from Serato DJ Pro. You can trigger these scratch-friendly samples by simply tapping a pad. You can even start the sample from a point that you specify.

Another new addition is the ‘Smooth Echo’ effect which is an industry first. This unique, ground-breaking control allows you to trigger the echo effects from a pad or fader. Simply assign the Smooth Echo effect to the fader or pad of your choice and you’re good to go. The S11 is the first mixer on the market to have this new feature – perfect for creating new sounds.

Plug and play MIDI mapping – control software within the mixer

Customise the way your mixer works by using the advanced MIDI mapping. From either Serato DJ or rekordbox, you can assign any button or knob from the mixer to control a wide variety of functions from your chosen DJ software. This allows you to get in-depth with your customisation, allowing you to truly create your own layout and playing style.

USB hub provides versatile connectivity

Stay connected. The rear of the mixer features a slew of connectivity including dual USB-A ports for DJ controllers. You can also hook up two CDJs via the HID mode. There are also two USB-B ports which are ideal for laptops, making DJ changeovers a seamless task.

Features

• Two-channel battle-style mixer – ideal for mixing, scratching and mashups
• Builds on the design of the S9 with a whole range of improvements and enhancements
• 4.3-inch touch screen with high-frame rate
• Touchscreen display waveform, track info, BPM info and much more
• Industry-first Smooth Echo – trigger an echo automatically from fader/pad you chose
• World’s first Deck 3/4 control – play up to four tracks with two virtual decks via the touchscreen
• Enhanced design, larger pads and low-latency performance
• Scratch banks – access scratch samples at the touch of a button
• Crystal-clear audio fidelity with 61-bit mixing and allow-jitter clock circuit with 32-bit, high-quality D/A conveter in the master output section
• Strengthened Magvel Fader Pro for improved stability
• 22 built-in effects including new Beat FX – add texture to your tracks
• Direct USB connection

Specifications

Audio/Power

• Frequency Range: 20 – 20000 Hz
• Power Supply: AC 100-240 V, 50 Hz / 60Hz
• S/N Ratio USB:
  • 115 dB (USB)
  • 105 dB (LINE)
  • 90 dB (PHONO)
  • 80 dB (MIC)
  • 90 dB (AUX)
• Distortion:
  • 0.003 percent (USB)
  • 0.005% (LINE)
• Master Level Meter Size: 9 segment

Channels

• EQ/ISO Range:
  • –∞ dB to +6 dB (ISO)
  • –26 dB to +6 dB (EQ)
• EQ/ISO: 3 band
• Reverse Channels: Yes
• Peak Limiter: Yes

Performance Control

• Channels: 2
• Sound Colour FX:
  • Filter
  • Dub Echo
  • Noise
  • Pitch
  • Wide Filter
• Beat FX:
  • Echo
  • Ducking Echo
  • Echo Out
  • Spiral
  • Helix
  • Delay
  • Reverb
  • Back Spin
  • One-shot Spin
  • Vinyl Brake
  • One-shot Brake
  • Flanger
  • Phaser
  • HP Filter
  • LP Filter
  • Trans
  • Kill
  • Roll
  • Fader Pitch
  • Fader Synth
• Deck 3/4 control: Yes

Effect Sampler

• 3-Band Isolator: Yes
• Auto BPM Counter: Yes

Crossfader

• Crossfader Type: Magvel Fader Pro
• CURVE Assignable: Yes
• Reverse Crossfader: Yes
• Feeling Adjustment: Yes

Microphone

• Mic Connection: XLR / 1/4-inch Jack Combo
• Talkover Attenuator: Yes

Sound Card

• Connection: USB (Type-B)
• Sample Rate: 24 bit
• Frequency: 48 kHz

Terminals

• Inputs:
  • 2 LINE (RCA)
  • 2 PHONO (RCA)
  • 1 MIC (XLR & 1/4 inch TRS Jack)
  • 1 AUX (RCA)
• USB:
  • 2 USB A ports
  • 2 USB B ports
• Outputs:
  • 2 MASTER (XLR, RCA)
  • 1 BOOTH (1/4 inch TRS Jack)
  • 2 PHONES (1/4-inch stereo jack, 3.5-mm stereo mini-jack)

Physical

• Dimensions (WxHxD): 267 mm x 107.9 mm x 452.2 mm
• Weight: 5.2kg
