The Pioneer DJ XPRS122 is an active loudspeaker with a 12-inch woofer. Part of Pioneers XPRS2 PA system, the XPRS122 is powered by a 2000W class D amplifier. This powerful speaker has a maximum SPL of 131 dB and a frequency range of 48Hz to 20mHz, providing a loud and clear output to your audience. Included is a customisable DSP EQ with four pre-set modes: Live, Music, Speech and Studio Monitoring. You can choose between these or set up your own custom mode and save it. You can save up to 16 user EQ modes for certain spaces and applications.
Housed in a robust black plywood cabinet with a hexagonal mesh grill and a carry handle, the XPRS122 is both rugged and portable. As a part of Pioneers XPRS2 PA system range integrates seamlessly with other XPRS2 models. This is a high quality PA speaker made with premium pioneer research and engineering.
Powerful Pioneer PA
Pioneer by name, pioneer by nature. Leaders in research and development for DJ and live sound equipment, Pioneer products are renowned as industry standard. Presenting the powerful XPRS2 PA system range, Pioneer’s answer to your need for a dynamic, versatile and portable sound system to broadcast your performances to your crowd. To provide a clear sonic picture, the XPRS122 Full range active speaker is fitted with a 12-inch woofer and a one-inch exit compression driver. A three inch voice coil for the woofer and a 1.75 inch voice coil for the compression driver enable the XPRS122 to have an impressive frequency response of 48Hz to 20kHz. Powered by a class D amplifier producing 2000W, and a max SPL of 131 dB, the XPRS122 speaker can easily fill your gig space with clear sound.
A versatile design, built to last
Four different DSP pre-sets are available to utilise for your acoustic space, you can choose between Live, Music, Speech, and Studio Monitoring depending on the role you’re using it for. If you need to EQ the XPRS122 for a certain venue, you can save up to 16 custom user DSP modes for reoccurring places and applications. Housed in a robust, black exterior, reinforced plywood cabinet with a hexagonal mesh speaker grille, the XPRS122 is extra sturdy. With a carry handle attached, the speaker unit is extremely portable and can be taken anywhere, it also features rubber feet for isolation when it its placed on the floor. The XPRS122 active loudspeaker is part of the Pioneer XPRS2 range and it integrates exceptionally with the Pioneer DJ XPRS1182S Active Subwoofer as a whole PA system. This Speaker is a cutting-edge Pioneer PA device, ideal for any event organisers with the need for a dynamic, customisable, and portable PA speaker.
Features
- Powerful full range Pioneer PA loudspeaker with a range of innovations
- 12inch woofer with a three-inch voice coil and a one-inch compressor tweeter
- Frequency response of 48Hz to 20kHz provides a clear and detailed sonic picture
- Maximum SPL of 131 dB allows the speaker to provide loud output for big spaces
- DSP EQ with four pre-set modes that allow you to tailor the speaker to your space
- 16 custom EQ settings can be saved by the user to suit reoccurring applications
Specification
- System Type: Multi-purpose, 2-way active loudspeaker with DSP controls
- Transducer Low: 12” woofer, 3” voice coil
- Transducer Driver: 1” exit compression driver, 1.75” voice coil
- Frequency Response (-6 dB): 48 Hz – 20 kHz
- Max SPL: 131 dB
- Power Rating: Class D 2000 W (peak)
- Pre-set DSP modes: Live / Music / Speech / Monitor
- Customizable User DSP Modes: 16
- Electronic Protection: Thermal / Overload / Digital Limiter / Compressor
- Connectors: Input: MIC / LINE (Combo) / HI-Z / LINE (Combo) / 3.5 mm STEREO MINI
- Output: MIX (XLR)
- Power Supply: 110 V – 240 V (50 Hz / 60 Hz)
- Power Consumption: 800 W
- Enclosure Construction: Plywood cabinet, black paint, rubber feet, metal handle
- Mounting: One standard metal pole-mount. 10 x M10 threaded inserts plus integrated pull-back cover
- Dimensions: (W x H x D) 14.28” (362.7 mm) x 25.07” (637 mm) x 13.78” (350 mm)
- Net Weight: 20.2 kg (44.6 lb)
- Product code: XPRS122
