Excellent groove handling
The Concorde DJ is considered the jack-of-all-trades, boasting accurate sound reproduction and excellent groove handling.
• The DJ is great for any style of music.
• It has a spherical stylus and an extremely balanced cantilever that provides outstanding rigidity.
• Not only does the cartridge have a most sufficient tracking ability, it also provides the DJs with the most needed stringency and very low record wear.
All in all: improved tracking, alongside of accurate sound reproduction and an excellent groove handling.
Concorde DJ technical data
- Stylus Type Spherical
- Tracking Force 4.0 g
- Output Voltage 6 mV
- Frequency Range 20-20.000 Hz
Output voltage at 1000Hz, 5cm/sec. – 6 mV
Channel balance at 1kHz – 1 dB
Channel separation at 1kHz – 22 dB
Channel separation at 15 kHz – 15 dB
Tracking ability at 315 Hz at recommended tracking force – 100 μm
Compliance, dynamic lateral – 14 μm/m N
Stylus type – Spherical R 18 μm
Tracking force range – 3 – 5 g
Tracking force recommended – 4 g
Internal impedance, DC resistance – 700 Ohm
Internal inductance – 450 mH
Recommended load resistance – 47 kOhm
Recommended load capacitance – 200-600 pF
Cartridge weight – 18,5 g
Replacement stylus unit – DJ
